The figure below shows the GX1164 board and its connector. J6 a 25 pin, D type, provides access to the 8 resistor channels. Two additional cPCI connectors (J1 and J2) are used to connect to the back plane and to pass in the PCI and PXI signals to the board.
GX1164 Board (side view)
