TS-387

General Purpose Video Test Set

  • Production Test Set for video inspection systems
  • Signals range from DC to analog CCD to composite and S-video (Y and C) signals (12 - 15 MHz)
  • Flexible general purpose RF switching in both 50 Ω and 75 Ω impedances
  • 6U PXI Instrument
Overview
Ordering

Notes

Arbitrary waveform generation synthesizes the video waveform, which allows discrete alteration of color amplitude, phasing, and custom test patterns.
